TFNEW NK-3211 Domestic ARM Custom Rack Server
Model: NK-3211 · SKU: 0601002
NK-3211: a custom server powered by a domestic 920 processor (2.6 GHz/24 cores, optional 32 cores), with up to 2x 3.5-inch + 2x 2.5-inch drive bays and a dedicated Atlas 300I slot.
Reference configuration
Integration
Fits your environment
Support
Selection & delivery
WHY THIS PRODUCT
NK-3211 Custom Server — Enterprise Server Platform
The NK-3211 is powered by a domestic 920 processor (2.6 GHz/24 cores, optional 32 cores), providing 2x 3.5-inch + 2x 2.5-inch drive bay storage capability and a dedicated Atlas 300I slot.
High-Density Computing
Powered by the domestic 920 processor to meet enterprise-grade workload requirements.
Flexible Storage Expansion
Up to 2x 3.5-inch + 2x 2.5-inch drive bays for elastic scaling of business data.
Enterprise Reliability
900W redundant power and efficient thermal design ensure stable 7x24 operation.
Specifications
| Processor | Domestic 920 series ARM processor (2.6 GHz/24 cores/24 threads), optional (2.6 GHz/32 cores/32 threads) |
|---|---|
| Storage | Up to 2x 3.5" and 2x 2.5" SATA/SAS drive bays; optional RAID card supports RAID 0,1,5,10,50 or passthrough; integrated display chip, 2x integrated gigabit Ethernet ports, 4x integrated 10GE/25GE ports, 1x integrated 1000Base-T management port |
| Expansion | 5x PCIe 4.0 x16 (1 slot dedicated to Atlas 300I; 4 standard slots) |
| I/O Ports | Rear: 1x VGA, 1x USB3.0, 1x USB2.0, 1x RJ45_RS232; 2x RJ45 network ports, 4x 10GE/25GE optical ports, 1x dedicated remote management port (RJ45) |
| Power | Standard 900W redundant, optional single 900W, input 110V-240V, 50/60 Hz |
| Operating Environment | Operating temperature 10°C ~ 35°C, relative humidity 20% ~ 80% |
| SKU | 0601002 |
| Warranty | - |
| Lead time | - |
Applications
Built for Real Business Workloads
Use this platform as part of a complete enterprise AI infrastructure solution.
AI Training and Inference
A high-performance compute node supporting private model training, inference and concurrent workloads.
Contact our team →Private Compute Infrastructure
Serves as the compute foundation of enterprise data centers for virtualization and hyper-converged scenarios.
Contact our team →HPC and Data-Intensive Workloads
High-throughput I/O and low-latency interconnect for scientific computing, engineering simulation and data analytics.
Contact our team →Deployment
A Clear Deployment Path
Move from requirement discovery to a validated configuration and supported delivery.
Requirements and Specification Review
Confirm key parameters such as compute selection, power consumption, storage and facility environment.
Configuration and Compatibility Validation
Validate PCIe topology, thermal airflow and full-load system stability.
Delivery and Technical Support
Provide factory test reports, environment pre-installation and full lifecycle technical support.
Resources
Project Resources
Request the current documents for the exact configuration your team is evaluating.
Product Datasheet
Review detailed technical specifications, dimensions and interface definitions.
Contact our team →Installation and Configuration Guide
Best practices for rack mounting, cabling and data center deployment.
Contact our team →Technical Consulting
Discuss customized solutions with TF NEW senior hardware engineers.
Contact our team →REQUEST A QUOTE
Get a Configuration and Quote for the NK-3211 Custom Server
Tell us about your required configuration scale and deployment timeline, and we will provide professional advice and a formal quotation.
